Mondial Piega 125cc
Piega 125 cc (Pre registered) - £2499 +RFL and Unregistered - £2999 +RFL
Why the Piega 125cc
7 highlights
01
ALLOY WHEELS
17 inch alloy wheels with a stylish colour finish
02
MODERN DESIGN
Designed by Rodolfo Frascoli and developed in the FB Mondial style and design center, with geometries and engineering that underline its peculiarity
03
DETAILS
The Piega has an extremely beautiful design with a close attention to detailsv such as the fins for the air intakes that immediately identify its personality
04
DISC BRAKES
Disc brakes with ABS front and rear, 4 piston radial caliper in the front, and 1 piston floating caliper in the rear
05
MOTO GP STYLE WINGS
Front wings give an aggressive look in the style of Moto GP bike designs
06
LED Headlight
The LED headlight gives great vison by night and also gives a clean modern look
07
LED INDICATORS
LED Indicators for added style and complete safety
Images
17 photos
Colours
3 finishes
FACTORY BLUE
GRAPHITE BLUE
MAGNESIUM
Videos
About the Piega 125cc
Introducing the PIEGA - an impressive 125cc motorcycle designed by Rodolfo Frascoli and developed at the F.B Mondial style and design centre. This bike boasts unique geometries and engineering, setting it apart from other motorcycles in its class. Notable features include the innovative double superimposed front lights, and the fins for the vents, which give the PIEGA a distinct personality.
Other advanced features of the PIEGA include a modern TFT for running data control, and the Dell'Orto injection system, which is specifically designed to deliver outstanding performance. Its sleek and streamlined "tail" and rear lights positioned on the license plate holder make it a standout on the road.
Under the hood, the PIEGA is powered by a single cylinder, 4 stroke, DOHC, 4 valves engine with a capacity of 124cc. It has a bore x stroke of 58 x 47 mm, and a compression ratio of 12.0:1. The bike can reach a max power of 10.0 kW at 9750 rpm, and a max torque of 10.5 Nm at 8000 rpm. The engine is lubricated by a wet sump, and features a liquid cooling system, along with electronic fuel injection and electric starting.
The PIEGA has a 6-speed transmission, and a 9.5L fuel tank. It weighs 135 kg in running order and is equipped with a 4 piston radial calliper front brake with a 300 mm disc diameter, and a 1 piston floating calliper rear brake with a 220 mm disc diameter. Its front and rear wheels have sizes of 2.75x17" and 3.50x17", respectively, with front and rear tires of 110/70-17" and 140/70-17". The bike can seat up to two people, and has a length of 2000 mm, width of 810 mm, height of 1070 mm, wheelbase of 1340 mm, ground clearance of 190 mm, and seating position height of 820 mm. Its suspension system consists of a Ø40 mm USD fork with a travel of 97 mm in the front, and a single shock absorber with a travel of 120 mm in the rear.
Overall, the PIEGA is an exceptional motorcycle that offers a combination of advanced features, performance, and unique design elements that are sure to turn heads on the road. The Piega presents itself as an affordable, A1 license-friendly option that brings some sportiness and futuristic styling to the table.
Piega 125 cc (Pre registered) - £2499 +RFL and Unregistered - £2999 +RFL
Read more
Other advanced features of the PIEGA include a modern TFT for running data control, and the Dell'Orto injection system, which is specifically designed to deliver outstanding performance. Its sleek and streamlined "tail" and rear lights positioned on the license plate holder make it a standout on the road.
Under the hood, the PIEGA is powered by a single cylinder, 4 stroke, DOHC, 4 valves engine with a capacity of 124cc. It has a bore x stroke of 58 x 47 mm, and a compression ratio of 12.0:1. The bike can reach a max power of 10.0 kW at 9750 rpm, and a max torque of 10.5 Nm at 8000 rpm. The engine is lubricated by a wet sump, and features a liquid cooling system, along with electronic fuel injection and electric starting.
The PIEGA has a 6-speed transmission, and a 9.5L fuel tank. It weighs 135 kg in running order and is equipped with a 4 piston radial calliper front brake with a 300 mm disc diameter, and a 1 piston floating calliper rear brake with a 220 mm disc diameter. Its front and rear wheels have sizes of 2.75x17" and 3.50x17", respectively, with front and rear tires of 110/70-17" and 140/70-17". The bike can seat up to two people, and has a length of 2000 mm, width of 810 mm, height of 1070 mm, wheelbase of 1340 mm, ground clearance of 190 mm, and seating position height of 820 mm. Its suspension system consists of a Ø40 mm USD fork with a travel of 97 mm in the front, and a single shock absorber with a travel of 120 mm in the rear.
Overall, the PIEGA is an exceptional motorcycle that offers a combination of advanced features, performance, and unique design elements that are sure to turn heads on the road. The Piega presents itself as an affordable, A1 license-friendly option that brings some sportiness and futuristic styling to the table.
Piega 125 cc (Pre registered) - £2499 +RFL and Unregistered - £2999 +RFL
Specification
Engine
ENGINE TYPE
Single cylinder, 4 stroke, DOHC, 4 valves / Single cylinder, 4 stroke, DOHC, 4 valves
DISPLACEMENT
124cc
BORE X STROKE
58 x 47 mm
COMPRESSION RATION
12.0: 1
RATED OUTPUT
14BHP
MAX. TORQUE
10.5 Nm at 8000 rpm
LUBRICATION
Wet sump / Wet sump
FUEL SUPPL
Electronic injection / EFI
EXHAUST SYSTEM
Euro 5 Compliant
CERTIFICATION
Euro 5
GEARBOX
6 Speed
FINAL DRIVE
Chain
IGNITION
Electric starter / Electric starter
COOLING SYSTEM
Liquid Cooled
STARTING
Electric
PRIMARY DRIVE
Chain
Chassis
FRONT SUSPENSION
USD fork Ø40 mm / Ø40 mm USD fork
FRONT BRAKE
4 pistons radial caliper with ABS
REAR SUSPENSION
Monoshock absorber / Single shock
REAR BRAKE
1 piston floating caliper / 1 piston floating caliper - 220 mm CBS or ABS
FRONT RIM TYPE
Alloy
REAR RIM TYPE
Alloy
REAR RIM DIMENSION
17 inch
FRONT TYRE
110 / 70-17 "
REAR TYRE
140 / 70-17 "
HEADLIGHT LAMP
LED
TAILLIGHT LAMP
LED
Dimensions
LENGTH
2000 mm
WIDTH
810 mm
HEIGHT
1070 mm
GROUND CLEARANCE
190 mm
UNLADEN WEIGHT
135kg
USABLE TANK VOLUME
9.5L
WHEELBASE
1340 mm
SEAT HEIGHT
820 mm
